Pair the airMAX® Sector Antenna with a Rocket™M BaseStation for sector coverage in Point-to-MultiPoint (PtMP) networks.
Features
- Mounting Universal Pole Mount
- RocketM Bracket
- Weatherproof RF Jumpers
Specifications
Dimensions: 700 x 135 x 73 (mm)
Weight: 5.9 kg
Frequency Range: 5.15 - 5.85 GHz
Gain: 18.6 - 19.1 dBi
HPOL Beamwidth: 123° (6 dB)
VPOL Beamwidth: 123° (6 dB)
Electrical Beamwidth: 4°
Electrical Downtilt: 2°
Max. VSWR: 1.5:1
Wind Survivability: 125 mph
Wind Loading: 20 lbf @ 100 mph
Polarization: Dual-Linear
Cross-pol Isolation: 28 dB Min.
ETSI Specification: EN 302 326 DN2
BREAKTHROUGH DESIGN AND PERFORMANCE
The innovative airMAX® Sector Antennas feature carrier-class construction and 2x2, dual-polarity performance.
REDUCED INTERFERENCE, HIGHER GAIN
Highly resistant to noise interference, the airMAX® Sector Antennas provide superior gain and beam performance for high-capacity, multipoint networks.
RF ISOLATION AND BEAMWIDTH OPTIONS
The versatile airMAX® Titanium Sector models feature advanced RF isolation and adjustable beamwidth options: 60°, 90° or 120°.
INDUSTRIAL-STRENGTH CONSTRUCTION
airMAX® Antennas are designed with robust mechanical design for outdoor application use.
PLUG AND PLAY INTEGRATION
Every airMAX® Antenna has a built-in Rocket™ mount, so no tools are needed to install the Rocket BaseStation.
