Simply45 is the industry-leading brand for RJ45 modular plug innovation and performance solutions.
The S45-1155 meets HDBaseT 3.0 standard.
The S45-1155 supports performance standards: ANSI/TIA 568.2-D for Cat7 and Cat6a; ISO/IEC 11801 Class F, Ea and E. Supports 10GBaseT performance applications over PE insulated shielded twisted pair cables.
3 Prong Pin Design with 50µ of True 24ct Gold Plating. All Simply45 Standard WE/SS RJ45 modular plugs use only 50µ 24ct gold plated 3-Prong pin design instead of a 2-Prong design as found on many other Standard RJ45 modular plugs. A 3-Prong pin provides 3 points of contact with the copper wire conductor instead of 2. This improves electrical performance and signal integrity. A 3-prong pin also holds stronger onto the wire conductors.
Solid LAN Cables. TheS45-1155 is ideal for most shielded 10G LAN cables with FPE (foamed polyethylene) wire conductors. Supports 23 AWG LAN cables with a maximum cable diameter of 8.0mm (0.315”) and wire conductor sizes 1.21mm – 1.45mm (0.047” – 0.057”). The S45-1155 works great with Cat7a, Cat7, Cat6a LAN cables with S/FTP, U/FTP, and F/FTP cable constructions.
Improved Crosstalk Performance. The unique internal design of the S45-1155 Standard RJ45 modular plug allows the LAN cable to be inserted further into the RJ45 plug. This reduces the length of untwisted wires improving NEXT performance. Our S45-1155 plug design and Bar45 provide the best crosstalk performance of any shielded RJ45 plug on the market.
Commercial Rated. These RJ45 mod plugs are UL94 V0 (IEC 60695-11-10) rated for all commercial installations. These RJ45 mod plugs are recommended for CMP Plenum, CMR, CM; and LSZH up to B2ca rated LAN cables.
Color Tinted RJ45 Modular Plugs. The S45-1155 comes with a light Orange tint for easy pass-through RJ45 modular plug identification. No more trouble identifying which plug is which. All Simply45 RJ45 modular plugs are color-coded for easy identification.
Wide Mouth Jar for Easy Hand Access. No need to spill RJ45 mod plugs out of the jar just to reach them. Most hands (unless you are “Shrek”) can easily reach the last plug in the jar.
Color-Coded Jar Caps. The S45-1155 jar cap is Orange matching the color tint of the RJ45 mod plug. This makes it very easy to find identify the items in your bag or kit. Saves time identifying the RJ45 modular plugs that you need to use.
UL Listed. The S45-1155 Standard WE/SS RJ45 modular plugs are UL Listed and bear the UL Logo on the Simply45 packaging. Only Simply45 provides the UL Listed logo for quality and safety on pass-through RJ45 modular plugs. UL is the strictest 3rd party verification service in the world and products bearing the UL mark represent the highest quality and safety standards.
PoE/PoH Rated. The S45-1155 is ideal for PoE/PoH applications. The S45-1155 uses the correct 3-Prong Pin design; true 24ct gold plated pins; fully shielded and is made using the highest quality materials for RJ45 modular plugs. This all ensures lower resistance and less heat build-up than cheaper-made RJ45 that are out on the market.
Compliant with Industry Standards. ANSI/TIA 568.2-D Class E, 1096-A; ISO/IEC 11801 Class E, 60603-7, 8877:1992; FCC
