Features
- The MicroScanner2 Termination Test Kit includes a MicroScanner2 cable verifier and an IntelliTone Pro 200 probe to verify cable functioning of new and existing copper and fiber network installations. Additionally, the kit contains the IS60 Pro-Tool Kit for efficient cable installation
- Revolutionary Interface – graphical wire map, length, cable ID, and distance to fault displayed on one screen
- Multimedia Support – tests all common media types including RJ11, RJ45, Coax, with no need for adapters
- IntelliTone Toning – locates virtually any cable or wire pair with IntelliTone digital and analog toning
- VDV Service Detection – verifies today’s media services, including 10/100/1000 Ethernet, POTS, and PoE
- Rugged Housing – integrated rubber holster enhances grip and makes it durable enough for the toughest jobs
- Oversized Display – large, backlit LCD makes results crystal clear whether in bright sunshine or in a dark closet
Specifications
Test Connectors: Twisted-pair: UTP, FTP, SSTP 8-pin modular jack accepts 8-pin modular (RJ45) and 4-pin modular (RJ11) plugs; Coax: F-connector for 75 Ω, 50 Ω, 93 Ω cables
Cable Tests: Length (460 m or 1500 ft. with resolution to 0.3 m or 1 ft.), wire map to TIA-568A/B standards, remote ID locators; displays results on one screen
IntelliTone digital tone: [500 KHz]
Analog tones: [400Hz, 1KHz]
PoE Detection: Solicits and detects the presence of 802.3af compatible PoE(Power over Ethernet) devices
Ethernet Port Test: Advertised speed of 802.3 Ethernet ports (10/100/1000)
Battery type: 2 AA (NEDA 15A, IEC LR6) alkaline batteries
Battery life: 20 hours of typical use
Other compatible battery types: 2 AA photo lithium, NIMH, NICAD
Dimensions: 3 in x 6.4” x 1.4 in (7.6 cm x 16.3 cm x 3.6 cm)
Weight: 0.8 lbs. (363 grams)
Display: Monochrome liquid crystal display (LCD) with backlight
Calibration: User-configurable NVP for twisted pair and coax; determines actual NVP with known length of cable
Operating Temperature: 32 °F to 113 °F (0 oC to 45 oC)
Storage Temperature: -4 °F to +140 °F (-20 oC to +60 oC)
Operating Humidity: 90 % (50 °F to 95 °F; 10 oC to 35 oC)
Shock Vibration: Meets requirements for MIL-PRF-28800F for Class 2 random vibration; 1 m drop test with and without wire map adapter attached
Altitude: 4000 m; Storage: 12000 m
EMC: EN 61326-1
Agency Certifications: N10140 C-Tick EMC standard; FCC Part 15 Class A; CE European Union Directives Pollution Degree 2
